Features
|
Tow cables included |
2″ hitch coupler |
|
Long lasting powder coat finish |
4-stage hydraulic filtration system |
|
Auto latch system for safe towing |
Heavy-duty 2″ x 3″ box tube tongue |
|
Heavy-duty 4 bolt trailer hubs for towing |
Offset valve for better operator positions |
|
Heavy-duty wedge features five bolts per side |
Heavy-duty log cradle, fenders and engine mount |
|
Heavy-duty crank down wheel jack for easy moving |
Service friendly design for checking hydraulic fluid |
|
Halite commercial cylinder seals for consistent pressure |
|
Specifications
| Cylinder | 4″ X 24″ clevis type, 1.75″ rod |
| Valve | 3 position with auto return |
| Pump | 11 GPM HI-LO 2 Stage |
| Hydraulic Tank | 9.0 Gallons System Total |
| Hydraulic Capacity | 10.0 Gallons System Total |
| Engine | Honda GX160 |
| Displacement | 163cc |
| Bed Height | 32″ |
| Beam | 6″ Heavy-Duty Formed Steel |
| Tires | 4.8″ x 8.0″ Highway Rated |
| Log Opening | 25″ |
| Cycle Time | Approx. 13 Seconds Complete Cycle |
| Splitting Force | Approx. 24 tons |
| Weight | 675 lbs. |
